6 Questions To Answer Before Requesting A Tube Filling Machine

Are you planning to contact the tube filling machine manufacturer for a price quote? That is great! But we recommend taking some time to make sure all parameters relevant to your project are pre-defined or not.

Tube filling machine manufacturers need to know critical details of your production line in order to give the most accurate option with adjusted pricing. A tube filling machine is not a conventional or usual machine; each machine is designed as per the unique requirements of the customers. So, you must be prepared for a bunch of queries when requesting a machine.

By keeping the manufacturer's perspective in mind, we help you get started, here’s a list of 6 questions to answer before requesting a tube filling machine and tips for how to answer.

Table of Contents

I. What do you want to fill? What is it used for?

II. What is the size of your tube? (dimension, length, shape)

III. What production capacity do you require? How much per tube?How many per hour?

Ⅳ.Which tube filling method do you require?

Ⅴ.What is your budget for this tube filling machine?

Ⅵ.When do you want to put it into production?

Conclusion

Ⅰ.What do you want to fill? What is it used for?

There are various makes and models of tube filling machines found in the market, each having its own unique features and specifications. You can fill many kinds of products in your tubes such as

Pharmaceutical Pain relief creams
Burn ointments
Muscle relaxing salves
Balms
Pharmaceutical
Food Sauces
Condiments
Condense Milk
Chocolates
Food
Cosmetics Lotions
Facial masks
Foundations
Skin fairness creams
Cosmetics
Chemical Pesticides
Insectides
Fertilizers
Adhesive
Lubricants
Chemical
Stationery Paints
Glues
Highlighters
Stationery

Your vendor must know about the type of product you are filling as various kinds of liquid require different filling methods and each machine has a particular filling method. So, the vendor can guide you with their expertise and knowledge in the selection of the best machine for your business.

Ⅱ.What is the size of your tube? (dimension,length,shape)

Decide on the size of tubes before looking for appropriate filling machines for your business. Knowing about dimension, length and shape is a main determining factor in the purchase of a machine as each machine handles specific size and shape of tubes.

The size of tubes normally depends upon filling volume and shape.

Tube Size

Tube sizes are normally in the range of 8 mm to 50 mm. The most commonly available sizes of tubes are 10 mm, 11.5 mm, 11.6 mm, 12.5 mm, 13.5 mm, 16 mm, 19 mm, 22 mm, 25 mm, and 30 mm.

The standard length of the tube is around 50 mm- 155 mm.

Tube Size

Tube Capacity

Filling volumes of tubes range from 1.5 ml to 400 ml

Tube Capacity

Tube Shape

Tubes are oval, round, and cylindrical in shape. Now a day, tubes also come in animal shapes.

Tube Shape

Tube Size Length Range Filling Capacity
8 mm 50 mm 1.5 ml
9 mm 57 mm 2-2.5 ml
10 mm 50 mm 3-3.5 ml
11.5 mm 54-64 mm 4-6 ml
11.6 54-64 mm 3-5 ml
12.5 mm 70-75 mm 5-7 ml
13.5 mm 65-82 mm 3-10  ml
16 mm 80-95 mm 5-12 ml
19 mm 70-110 mm 8.8- 20 ml
22 mm 90-120 mm 10-30 ml
25 mm 105-150 mm 30-50 ml
30 mm 115-155 mm 50-80 ml
32 mm 155-165 mm 60-80 ml
35 mm 175 mm 150-180 ml
40 mm 165-190 mm 100-200 ml
50 mm 180-205 mm 200-400 ml

The above-mentioned chart helps new customers in estimating accurate length range according to their required filling capacity. The standard length of tubes and filling volume differ with the model of the machine and forming material of the tube.

Ⅲ.What production capacity do you require? How much per tube? How many per hour?

It is of prime importance when contacting for machine supplier you must know the major information about your production requirement. Production capacity also depends upon the number of labor/technicians in your plant, the size of the warehouse, your required output, the time you need to deliver your product to market, and the number of raw materials present in your inventory. By considering your production requirement (tubes/hour), vendor can offer types of machines to run the process smoothly. For instance:

Type of Machines

Type of Machines

Type of Machine Filling Capacity
Manual 600-1200 tubes/hr
Semi-automatic 720-1500 tubes/hr
Automatic 2400-45600 tubes

The amount of tubes filled per hour varies with different types of tube filling machines. Manual and semi-automatic machines cannot meet the production and output requirements of large filling plants so it would be unfeasible for large business owners to buy these machines. As each filling machine has its own set of pre-programmed filling parameters so inform your vendor about your filling needs. Manual or semi-automatic machines are small-sized and have a small number of nozzles while automatic machines have larger sizes and a large number of filling devices so can fill many tubes simultaneously.

Ⅳ.Which tube filling method do you require?

It is imperative that you should know about your tube filling method. Usually, there are three types of filling methods

Vacuum Filling Vacuum pumps and a vane feeding system are required for this kind of filling. The filling material is gradually loaded inside feeding cells from the hopper by means of the vacuum pump.
Gravity Filling The filling liquid is poured inside the tubes using gravitational force. This method used filling nozzles for accurate filling. The time of filling is programmed by the operator.
Piston Filling In this method, a cylindrical device is filled with contents first, and then via pistons, the contents are pushed into the tubes.

The filling method of tube filling machines determines the kind of parts present in machines like nozzles, vacuum pumps, and pressure pumps. Consult with your vendor about your filling machine so that manufacturer can design the machine according to your needs.

Ⅴ.What is your budget for this tube filling machine?

Your wallet is deciding factor for the kind of tube filling machine will you purchase. Discuss your budgeting finances with your vendor when making the purchase.

tube filling machine-1

Your finances determines several aspects of tube filling machines such as

  • Automation
  • Size
  • Safety Features like switches, alarms, etc
  • Programming features such as touch screens
  • Cleaning and maintenance
  • Filling efficiency

Bigger tube filling machines with the latest technologies are fully automated but have higher prices. Large manufacturing units will easily afford them. But for smaller businesses manual or semi-automatic tube filling machines are more appropriate and the price of the machine will easily fall under the budgeting capital of these firms. Assess all the features of the machines and your purchasing funds before making a decision.

Ⅵ.When do you want to put it into production?

It is important that you should inform your vendor tell the time period in which you want to operate your new tube filling machine. Deciding on the operating date will give the manufacturer deadline to complete processes involve in shipping such as

  • Processing orders
  • Preparing quotations
  • Safety and quality assurance
  • Factory acceptance test certification
  • Procurement of materials for manufacturing of tube
  • Mode of transportation (by sea or air)

All the above-stated factors affect the date of the machine’s delivery. So, consult with your manufacturer for timely machine delivery.

Conclusion

6 Questions To Answer Before Requesting A Tube Filling Machine encorporates all the possible queries that any manufacturer would inquire from the buyer. Ensuring that these are well worked up before approaching the manufacturer will increase smooth communication between both parties. For further assistance contact our 24/7 support on how to properly prepare required documents.
