HLSG Series High Speed Wet Mixing Granulator

The machine has consistent programmed technology(main-machine interface if option selected) and can get assured of stability in quality,as weel as easy manual operation for convenience of technological parameter and flow progress.

FEATURE

  • Adopt frequency speed adjustment to control the stirring blade and cutter,easy to control the size of particle.
  • With the rotating shaft hermetically filled with air,it can prevent all dust from compact.
  • With a structure of conical hopper tank,all meterials can be uniform rotation.The tank is laid with an interlayer on the bottom, in which water cooling citculation system featuring higher thermostatic performance than air cooling system is furnished,which leads to improve the quality of particles.
  • With automatic lifting of the pan cover,the tank outlet matching with drying devices,self-equipped arm-ladder,it is easy to operate,self-equipped arm-ladded,and easy to operate.
  • Lifting system with paddles is more benefical to clean paddles and pot body.

DATA SHEET

Model

HLSG-10

HLSG-50

HLSG-100

HLSG-200

HLSG-300

Working capacity

2-8

12-35

25-70

80-120

130-180

Time of Granulating/batch

(Mixing:about 2minutes,Granulaion:about 7mintues/batch)

Rotating Speed of Stirring Paddle(rpm)

50-500

25-500

30-250

30-250

30-220

Power of stirring motor (kw)

2.2

5.5

7.5

15

18.5

Rotating Speed of Cutter(R/M)

50-3000

50-3000

50-3000

50-3000

50-3000

Power of Cutting knife motor(KW)

0.75

1.5

3

4

7.5

Overall dimension (L×W×H)(mm)

1350X540X1300

1935X662X1575

2078X702X1720

2268X910X2010

2600X1000X2130

Height of Discharge Outlet(mm)

796

796

796

920

985

Weight(Kg)

330

400

700

1100

1350
