How will You Benefit From AIPAK Semi Automatic Capsule Filling Machine?
High Accuracy Filling
Precise dosing system ensures consistent capsule weight.
Easy Operation
Simple controls, quick setup and cleaning.
Cost-Effective
Ideal for small-scale production or pilot batches.
Quick Changeover
Switch capsule sizes in minutes.
Wide Application
Works with powders and granules.
High Capacity
Only one operator required less space occupation.
AIPAK Semi Automatic Capsule Filling Machine Applications
Herbal & Nutraceutical
Filling herbal extracts or vitamins
Veterinary
Animal health and supplement capsules
R&D & Pilot Use
Ideal for universities or small labs
Why Choose Us?
10+ years manufacturing experience
Exported to 50+ countries
Full line solutions: capsule filling + polishing + counting
Less cost but high productivity
Get Your Semi automatic Capsule Filling Solution Today!
We provide complete Semi automatic Capsule Filling solutions tailored to your production needs.
Fill out the form below and we’ll respond within 12 hours with detailed specifications and pricing.
Semi automatic Capsule Filling Machine FAQs
1.What capsule sizes can this machine fill?
It can fill all standard capsule sizes from #00 to #5.
Changing the capsule size is quick and easy by replacing the corresponding mold set.
2.What is the production capacity?
Depending on the operator’s skill and capsule size, the output ranges from 20,000 to 25,000 capsules per hour.
3.Can it fill sticky or oily materials?
The machine is mainly suitable for dry powders and granules.
For sticky or oily materials, pre-drying or using special feeders is recommended.
4.How accurate is the capsule filling?
The filling accuracy is within ±3%, depending on powder flowability and operator handling.
5.How does the machine operate?
Operation includes:
- Loading empty capsules into the loader.
- Separating capsule bodies and caps automatically.
- Filling powder using a dosing tray and tamping mechanism.
- Locking and ejecting the filled capsules.
It’s simple to operate and requires minimal training.
6.What materials is the machine made of?
All contact parts are made from SS304 or SS316 stainless steel, ensuring hygiene and compliance with GMP standards.
7.How long does it take to change capsule sizes?
It takes around 10–15 minutes to change molds and adjust the filling tray for a new capsule size.
8.Do you provide installation and training?
Yes. We provide video tutorials, online technical support, and can arrange on-site installation or operator training upon request.
9.What is the delivery time and warranty?
Delivery: Usually within 15–20 working days after order confirmation.
Warranty: 1-year warranty with lifetime technical support and spare parts supply.
10.Can this machine be upgraded to a full automatic line?
Yes. You can start with the semi automatic version and later integrate capsule polishing, sorting, and counting machines for a complete capsule production line.
11.Is it suitable for R&D and pilot production?
Absolutely. It’s widely used by R&D labs, universities, and small-scale manufacturers due to its compact size, low maintenance, and affordable cost.
